Talking about Battery pack core components-battery cell (2)

Overdischarge to zero voltage test:



The STL18650 (1100mAh) lithium iron phosphate power battery was used for the discharge to zero voltage test. Test conditions: 1100mAh STL18650 battery is fully charged with a 0.5C charge rate, and then discharged to a battery voltage of 0C with a 1.0C discharge rate. Then divide the batteries placed at 0V into two groups: one group is stored for 7 days, and the other group is stored for 30 days; after the storage expires, it is fully charged with a 0.5C charging rate, and then discharged with 1.0C. Finally, the differences between the two zero-voltage storage periods are compared.



The result of the test is that after 7 days of zero voltage storage, the battery has no leakage, good performance, and the capacity is 100%; after 30 days of storage, there is no leakage, good performance, and the capacity is 98%; after 30 days of storage, the battery is subjected to 3 charge-discharge cycles, The capacity is back to 100%.



This test shows that even if the lithium iron phosphate battery is overdischarged (even to 0V) and stored for a certain period of time, the battery will not leak or be damaged. This is a feature that other types of lithium-ion batteries do not have.
