480CCA Portable car emergency jump starter battery QQ/PN1B-20Ah

Short Description:

Battery specifications:

Model
QQ/PN1B-20Ah
Operating Voltage Range (V)
8.0~16.0
Nominal Voltage (V)
12
Nominal Capacity (Ah)
20
Minimum Capacity (Ah)
≥19
Rated Energy (Wh)
240
Maximum Discharge Power @ 3 Seconds (W)
1200
Fast Charge Voltage (V)
14.6
Standby Charge Voltage/Float Charge Voltage (V)
14.2
Standard Charge Current (A)
20
Recommended Charge Current (A)
≤20
Maximum Charge Current (A)
60
Standard Discharge Current (A)
20
Maximum Discharge Current (A)
≤60
Cold Cranking Current (CCA)
480
Internal Resistance (mΩ)
≤10
Charging Temperature (°C)
-20~50
Discharging Temperature (°C)
-40~80
Cycle Life (25°C, 0.5C, 70% DOD)
>3000
Cell Configuration
32140-4S2P
Dust and Water Resistance Rating
IP65
Weight (kg)
Approx.：5.5
Dimensions (L*W*H, mm)
260*140*190


Product Detail

Product Tags

The QQ/PN1B-20Ah is a powerful, fast-charging, and durable jump starter battery. It combines massive starting power with quick recharge capabilities and a robust build, making it an excellent and reliable solution for emergency vehicle jump-starts.
